Scaling LLMs to hundreds of billions of parameters has made the traditional “load-every-weight” dense approach an energy nightmare. Since data movement across the memory wall, not computation itself, dominates the energy footprint, sparsity offers a vital solution. To ensure sustainable growth, model architectures must evolve beyond monolithic dense execution toward strategic sparsity. By selectively activating only the sub-networks relevant to the immediate task – whether focusing on a specific segment of the context window or a specialized domain of expert knowledge – we drastically reduce the volume of data shuttled between memory and compute units. This fundamentally lowers the energy cost per token, making LLMs commercially and environmentally viable.

Hybrid Architectures: Dense Capabilities and Sparsity

The drive for memory efficiency has fueled the trend of developing complex hybrid architectures, such as Samba and Jamba, which combine dense capabilities with novel sparsity mechanisms. Importantly, sparsity is not a single architectural choice but a spectrum of techniques that can be composed together. For instance, Jamba complements its hybrid State Space Model (SSM)-Transformer backbone with Mixture-of-Experts (MoE) routing.

This proves that MoE acts as an orthogonal architectural enhancement that can be integrated independently of the primary sequence-modeling mechanism. Samba takes a different approach, alternating between selective SSMs and Sliding Window Attention (SWA), a form of sparsity that limits each token to focusing only on a fixed local window of context instead of the entire document.

In our empirical architecture studies evaluating these combinations, we found a distinct crossover point: while fully dense models perform efficiently for short to medium contexts, linear attention alternatives like SSMs achieve a massive advantage at long context lengths (e.g. beyond 8K tokens). Because linear attention avoids the quadratic scaling of the KV-cache, it delivers significantly higher throughput and up to a 4x reduction in energy per token for extremely long documents.

Hybrid models like Jamba and Samba aim to capture the best of both worlds, retaining dense capabilities for multi-hop reasoning while relying on linear layers and sparsity to handle long-range context efficiently.

The MoE Communication Bottleneck

In our future work, we will explore another critical dimension of sparsity: Mixture-of-Experts (MoE) architectures and sparse attention mechanisms. By allowing a model to selectively activate only the sub-networks relevant to the immediate context, MoE drastically lowers the compute and memory bandwidth requirements per token.

However, the “no free lunch” trade-off becomes evident when scaling: while MoE reduces per-token FLOPs, it introduces a severe All-to-All collective communication bottleneck. In an Expert Parallelism (EP) configuration, tokens must be dynamically routed to their corresponding experts across different nodes, shifting the bottleneck from raw compute to inter-node interconnect bandwidth.

The Next Frontier: Mastering data-centric Optimization

Quantifying the energy footprints and mitigating this MoE communication tax – specifically the delicate interplay between sparse parameter activation and intensive inter-device traffic – represents the next major frontier in our performance engineering. Ultimately, the evolution of next-generation LLMs hinges on mastering data-centric optimization, balancing active parameter efficiency with fluid data movement across both memory and network fabrics.

Author: Bole Ma from NRH@FAU

Header image copyright © ittipol – stock.adobe.com / edited by Fraunhofer IIS
